JQ15 Air Diaphragm Pump

  • JQ15

Product Description



Wetted Parts Material: PP/PVDF/Aluminum/Stainless Steel

1/2 in (12.7 mm)  center- and end-porting
• No seals to leak or fail
• Quiet running — less than 85 dB with easy-to-use remote muffler capability for even lower noise levels
• High flow rates in a small, portable package
• External controller for optional remote operation

• Machine lubrication servicing
• Drum evacuation
• Plating and dip tanks
• Water treatment

Typical Fluids Handled:
• Cleaning fluids and detergents
• Chemicals
• Ceramic glazes
• Inks
• Solvents and flammables
• Acids and bases

Technical Specifications:

Max Working Pressure 100psi(0.7Mpa ,7bar)
Max Flow Rate 15gpm(57lpm)
Max Reciprocating Speed 400cpm
Max Suction Height (Dry Sucking) 4.5m
Max Permitted Grain 3/32in.(2.5mm)
Max.Air Consumption 20gpm(10L/s)
Air Inlet size 1/4in.npt(f)
Air Outlet size 3/8in.npt(f)
Fluid Inlet size 1/2 in.npt(f)or bspt(f)
Fluid Outlet size 1/2 in.npt(f)or bspt(f)

 PVDF pump 3.7kg PP pump 2.7kg

Aluminum pump 4.5kg; Stainless Steel 6.8kg
